SMPS

STLS-0050 (50W LED)

- Input

· Input Voltage Range : AC85~265 (47~63Hz) or DC 120~370

· Efficiency (200VAC)(typ) : 80%이상

· Inrush Current : 50A 이하

· Leakage Current : 1mA 이하

- Output

· Nominal Output Voltage : 50.0V

· Maximum Output Voltage: 1.0A

· Maximum Output Power : Total 50W

· Load Regulation +/-2%

· Lind Regulation : +/-1%

STS-0110

- Input

· Input Voltage Range : AC85~265 (47~63Hz) or DC 120~370

· Efficiency (200VAC)(typ) : 70%이상

· Inrush Current : 50A 이하

· Leakage Current : 1mA 이하

- Output

· Nominal Output Voltage : 33.0V (DC30-35V 가변), 12.0V

· Maximum Output Voltage: 33.0V 3A, 12.0V 500mA

· Maximum Output Power : Total 110W

· Load Regulation +/-2%

· Lind Regulation : +/-1%

STLS-0022A (SKY-M100)

- Input

· Input Voltage Range : DC60~300V

· Efficiency (200VAC)(typ) : 70%이상

· Inrush Current : 50A 이하

· Leakage Current : 3mA 이하

- Output

· Nominal Output Voltage : 15V, -15V, 5V, 3.3V

· Maximum Output Voltage: 15V 600mA, -15V300mA, 5V 1A, 3.3V 100mA

· Maximum Output Power : Total 22W

· Load Regulation +/-2%

· Lind Regulation : +/-1%

STLS-0034R5A (STL-3001)

- Input

· Input Voltage Range : AC85~265 (47~63Hz) or DC 120-370

· Efficiency (200VAC)(typ) : 80%이상

· Inrush Current : 50A 이하

· Leakage Current : 1mA 이하

- Output

· Nominal Output Voltage : 11.5V

· Maximum Output Voltage: 3.0A

· Maximum Output Power : Total 40W

· Load Regulation +/-2%

· Lind Regulation : +/-1%
